Cooper S Convertible (R57) L4-1.6L Turbo (N14) (2009)
/l4-1.6l_turbo_(n14)/Page-871002.png)
Note:
For purposes of clarity, illustration shows and description refers to the removed high-pressure rail.
Disconnect plug connections (1) of fuel injectors (2).
Disconnect plug connection (1) for high-pressure sensor.
Detach wiring harness (2) from high-pressure rail (3).
Release screws.
Tightening torque 13 53 3AZ See: Specifications/13 53 Fuel Injectors and Lines.
Detach high-pressure rail (3) from cylinder head and remove.
