Aura L4-2.4L Hybrid (2009)
Body / Frame Mount Bushing: Service and Repair
Frame Cushion or Insulator Replacement
Tools Required
J-45725 Frame Bushing Installer
Removal Procedure
1. Remove the frame. Refer to Frame Replacement (2.4L) ()Frame Replacement (3.6L) ().
2. Remove cradle bushing with a rubber mallet.
Installation Procedure
1. Install clamp J-45725 onto the bushing leaving about an 1/8 inch from the bottom of the bushing.
