Octavia Mk1

Replacing front or rear silencer
Replacing front or rear silencer
Special tools, test equipment as well as aids required
t  Torque wrench 5 to 50 Nm (e.g. -V.A.G 1331-)
t  Body saw (e.g. -V.A.G 1523-)
A separation point is provided for repair purposes for replacing the front silencer or rear silencer.

–  Separate exhaust pipe at right angles at the separation point -arrow 2- with body saw (e.g. -V.A.G 1523 -).
–  When installing clamping sleeve -4- position on the side markings -arrows 1 and 3-.
–  Align exhaust system free of stress → Chapter.
–  Align rear silencer horizontally.
–  Tighten bolted connections of clamping sleeve evenly to 40 Nm.
–  Installation position of clamping sleeve: horizontal in vehicle, bolted connections pointing forward.
  A26-0130
