15. Attach ATF cooler hose to a clip under the radiator main fan shroud.

16. Connect connectors to radiator main fan (A) and sub fan (B) motors.
17. Install under cover.
18. Lower the vehicle.

19. Connect battery ground cable.
20. Fill engine coolant.
