Verona L6-2.5L (2005)
Knee Diverter: Service and Repair
Driver's Side Knee Bolster Removal and Installation
Driver's Side Knee Bolster Removal
1. Remove the coin storage and the screws.
2. Separate the hood release cable from the hood latch release handle.
3. Carefully pull the instrument panel under cover until the mounting clips are released and the instrument panel under cover.
4. Remove the bolts from the driver's side knee bolster.
5. Remove the knee bolster.
Driver's Side Knee Bolster Installation
