Verona L6-2.5L (2005)
Child Seat: Service and Repair
Child Seat Anchorage Removal and Installation
Child Seat Anchorage Removal
1. Remove child seat anchorage cover.
2. Remove bolt and the child seat anchorage.
Child Seat Anchorage Installation
1. Install the child seat anchorage with the bolt.
Tighten:
Tighten the child seat anchorage bolt to 10 N.m (89 lb.in).
2. Install the child seat anchorage cover.
