Celica GT L4-1.8L (1ZZ-FE) (2001)
Suspension Strut / Shock Absorber: Service and Repair
Front Strut Assembly
Removal and Installation
REMOVAL
1. REMOVE FRONT WHEEL
Torque: 103 Nm (1,050 kgf-cm, 76 ft. lbs.)
2. DISCONNECT ABS SPEED SENSOR WIRE HARNESS CLAMPS FROM SHOCK ABSORBER
Remove the bolt and disconnect the ABS speed sensor wire harness clamp.
Torque: 8.0 Nm (82 kgf-cm, 71 inch lbs.)
3. DISCONNECT FLEXIBLE HOSE
Remove the bolt and disconnect the flexible hose from the shock absorber bracket.
Torque: 19 Nm (192 kgf-cm, 14 ft. lbs.)
