Removing & Installing Front Door Trim Panel for Volkswagen Jetta

Body repair work.

Removing and installing instrument panel - Jetta

Removing and installing front door trim panel - Jetta



Locking knob Finger plate and escutcheon ◆ Lock washer ◆ Countersunk screw Arrnrest ◆ 2 sealing washers ◆ 2 Phillips screws ◆ Removing => Fig. 1 Window crank ◆ Crank backing ◆ 1 countersunk screw ◆ Stiff window winder operation =>page 58-8



Door trim panel Phillips screws with cover Caution! Lock window crank screw connection with single-component locking fluid. Degrease thread before coating with locking fluid. For securing screw connection with single-component locking fluid we recommend: Omnifit Loctite screw locking agent

→ Fig.1 Removing door trim panel - Jetta

‒ Remove locking knob.
‒ Unclip finger plate for inner door opening mechanism and unscrew plate.
‒ Lever off protective caps of Phillips screws -3-.
‒ Remove 4 Phillips screws.
‒ Unscrew window crank.
‒ Remove Phillips screws -1- from armrest.
‒ Swivel armrest (handle and armrest are rigidly connected) 90° upwards, pivoting at point -2-, and remove.
‒ Unclip door trim panel.

Important
On door trim panels with integral loudspeaker -E- disconnect lead at central plug connector.
