Electrical system

Servicing anti-theft alarm (ATA)

Removing and installing anti-theft alarm system horn (H8)

The anti-theft alarm system horn is located in front left wheel housing, by suspension strut.

Removing:

‒ Remove front left wheel housing

=> General body repairs; Repair group 66; Exterior equipment; Removing and installing wheel housing liner

N96-0004

‒ → Pull 2-pin connector -2- off horn -3-
‒ Remove securing nut -1-

Installing:

Install in reverse order.
