RDX L4-2.3L Turbo (2008)
7. Detach the clips and release the fastener (A), then pull back the front carpet (B) from under the dashboard.
8. From back of the front carpet: Release the hooks (A) of the base (B) with a flat-tip screwdriver, and push up the projections of the holder from the
base to remove the floor mat holder (C).
9. Detach the clips, then pull up the rear carpet from under the seat side bolster both sides. Pull back the rear carpet (A), and remove it.
10. Install the front carpet and rear carpet in the reverse order of removal, and note these items:
-
Take care not to damage, wrinkle or twist the front and rear carpets.
-
Make sure the seat harnesses are routed correctly.
-
Slip the rear carpet under both seat side bolster.
-
Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.
-
Push the fasteners and clips into place securely.
