Heating and ventilationThird phase
  1. Press the various buttons shown in the table below
    and check that the illustrated code appears on the
    "TEMP" display each time a button is pressed.

NOTE: Do not press the "AUTO" button as this will
cause the system to pass on to the next self-diagnosis procedure.

BUTTONRELATIVE CODE
56
72
4d
79
bc
AE

Third phase

NOTE: All of the following stages must be carried
out when the vehicle is in the repair shop (internal and external temperatures stabilized between 10 and 30°C).

  1. Press the "AUTO" button.
    The indications given in the illustration below, 6 bars
    (which must stay on for the duration of the phase in progress) must appear on the "AIR" display and none of the leds must be on.
    Illustration showing six bars lit up on an AIR display with no LEDs illuminated
  2. Press the "AIR-" button.
    A plausible passenger compartment air temperature
    value must appear on the "TEMP" display.
    Display showing a numerical temperature reading of 24°C
  3. Press the "AIR+" button.
    A plausible external air temperature value must appear on the "TEMP" display.
    Display showing an external temperature reading of 32°C with a symbol indicating outside conditions
