HEADLAMP WASHER - WIRING DIAGRAM

1.8 T.SPARK, 2.0 JTS, 1.9 JTD 16V

Wiring diagram

Components

Component code	Name	Assembly reference
B1	JUNCTION UNIT
B1	JUNCTION UNIT	Op. 1080B EXHAUST EMISSION CONTROL SYSTEM
B1	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
B5	MAXI FUSE-1 BOX
B99	MAXIFUSE BOX ON BATTERY	Op. 5530B BATTERY AND LEADS
C11	RIGHT FRONT EARTH ( FRONT )
C15	FACIA EARTH, DRIVER''S SIDE
H1	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
H5	STEERING COLUMN SWITCH UNIT	Op. 5550A STALK UNIT
J50	HEADLAMP WASHER TIMER RELAY
M1	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
N25	HEADLAMP WASHER PUMP MOTOR	Op. 5050D HEADLAMP WASH/WIPE

3.2 V6

Wiring diagram

Components

Component code	Name	Assembly reference
B1	JUNCTION UNIT
B1	JUNCTION UNIT	Op. 1080B EXHAUST EMISSION CONTROL SYSTEM
B1	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
B5	MAXI FUSE-1 BOX
B99	MAXIFUSE BOX ON BATTERY	Op. 5530B BATTERY AND LEADS
C11	RIGHT FRONT EARTH ( FRONT )
C15	FACIA EARTH, DRIVER''S SIDE
H1	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
H5	STEERING COLUMN SWITCH UNIT	Op. 5550A STALK UNIT
J50	HEADLAMP WASHER TIMER RELAY
M1	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
N25	HEADLAMP WASHER PUMP MOTOR	Op. 5050D HEADLAMP WASH/WIPE
