5000S Wagon L5-2309cc 2.3L SOHC (NF) (1988)

  • Maintenance
  • Alignment
  • System Information
  • Specifications

Page 1
background image

Alignment: Specifications



Caster Angle

-1/6 to +1 1/2 deg







Caster Angle Desired

2/3 deg







Camber Angle

-1 to 0 deg







Camber Angle Desired

-  1/2 deg







Toe-In

-1/6 to +1/12 deg
