80 Quattro L5-2309cc 2.3L SOHC (NG) (1988)

  • Maintenance
  • Alignment
  • System Information
  • Specifications

Page 1
background image

Alignment: Specifications



Caster Angle

+3/4 to +1 3/4 deg







Caster Angle Desired

1 1/4 deg







Camber Angle

-1 2/3 to -2/3 deg







Camber Angle Desired

-  5/6 deg







Toe-In

0 to +1/3 deg
