background image

Alignment: Specifications



Caster Angle

+3/4 to +1 3/4 deg







Caster Angle Desired

1 1/4 deg







Camber Angle

-1 1/4 to -1/4 deg







Camber Angle Desired

-  3/4 deg







Toe-In

0 to +1/3 deg
