A4 Mk2
| Servicing clutch mechanism |
Caution
|
Note| t | Lubricate all bearings and contact surfaces with polycarbamide grease -G 052 142 A2-. |
| t | Before working on pedal cluster, remove storage compartment on driver's side → Rep. Gr.68. |
| t | Make sure that no brake fluid escapes into the footwell, the plenum chamber or onto the gearbox below. If this does happen, clean the affected area thoroughly. |
| t | When performing work in the footwell, put cloths on the carpet to protect it from possible brake fluid spills. |
| I - | Pedal cluster (LHD vehicles) - exploded view → Chapter |
| II - | Pedal cluster (RHD vehicles) - exploded view → Chapter |
| III - | Hydraulics - exploded view → Chapter |
