A6 Quattro Sedan V8-4.2L (BVJ) (2007)
/Page-6832002.png)
Version 1:
-
Release securing tabs - arrows - and then release retainer clips - 1 - and - 3 through 5 -.
-
Remove retainer from harness connectors - 2 -.
Version 2:
-
First release securing tabs - arrows - and then retaining clips - 1, 2, 3, 4, 6, 7 -.
-
Remove retaining cage from multi-pin electrical connector - 5 -.
Installing
Install in reverse order of removal, noting the following:
NOTE: Ensure O-rings - 1 - and - 3 - are not damaged.
-
Slide harness connectors - 4 - into retainer - 2 - until they audibly engage.
