Timing Belt: Specifications
Dimensions

Belt Damper Dimensions

Adjust position of tensioning roller until damper length -a- is within specified range.

Damper length -a-:

Engine cold: 136-139 mm (5.35-5.47 inch).
Engine warm: 126-129 mm (4.96-5.08 inch).
