Q7 Quattro V6-3.6L (BHK) (2007)
/Page-5639001.png)
Air Duct: Service and Repair
Air Duct Vent Grille
Air Duct Vent Grille
Removing
-
Remove door trim.
-
Remove air duct.
-
Release clips - 2 - and - 3 -.
-
Slide vent grille - 1 - to outer side - arrow - and remove from door trim.
Installation
To install, perform the steps used in removal in reverse order.
