Q7 Quattro V6-3.6L (BHK) (2007)
/Page-1799002.png)
-
Free up B+ wire - arrow - on oil dipstick guide tube.
-
Remove bolt - 2 - and remove oil dipstick guide tube.
-
Disconnect vacuum hose - 1 -.
-
Disconnect electrical connector - arrow - on Intake Manifold Runner Control (IMRC) valve (N316), unclip valve from bracket and lay aside.
-
Free up electrical wires on small left coolant pipe.
-
Loosen bolt - 1 - and remove bolt - 2 -.
