Q7 Quattro V6-3.6L (BHK) (2007)

Page 1
background image

Data Link Connector: Locations

Electrical/electronic components and installed locations 0AT, 6 Speed AWD A/T

Data Link Connector (DLC)

Location: Diagnostic connector is located in passenger side footwell.
