Steering Gear: Diagrams – Audi S4 V8-4.2L (BHF) (2004)

Steering Gear: Diagrams

Power steering gear, assembly overview

The illustration applies to 4-cylinder, 6-cylinder and 8-cylinder engines
The power steering gear is removed and installed complete with tie rods.

1 - Power steering gear with tie rods

^

Removing and installing (left-hand drive)

2 - Combi bolt, 40 Nm plus an additional 90° 1/4turn

^

Always replace

3 - Bolt, 30 Nm
4 - Steering column
5 - Rubber boot in bulkhead

^

Check for tears and chafing

^

Note correct installation position

6 - Combi bolt, 40 Nm plus an additional 90° 1/4 turn

^

Always replace

7 - Hex bolt
8 - Bolt
9 - Self-locking nut

10 - Hub carrier (steering arm)
11 - Banjo bolt, 47 Nm
12 - Oil seal

^

Always replace

13 - Return hose
14 - Return hose connection, 40 Nm

^

Colored markings must line up
