1 Series E81 130i (N52K) 3-door
View of thigh support mechanism:
1.
End stop for thigh support
2.
Locking mechanism for thigh support
View of seat frame mechanism:
3.
Guide rail on seat with depth arrester
4.
Guide rail on seat with end stop
Unfasten plug connection (1) and disconnect.
Note:
Check guide rails (2) and adjustment mechanism (3) for
damage.
RA Removing and installing/replacing thigh support on left or right front seat (spo
