1 Series E87 116i (N45) 5-door
Install plug (1) for pulse generator of inlet camshaft.
Note:
Lock on plug (1) must snap audibly into place.
Install inlet and exhaust adjustment unit.
Install cylinder head cover.
Install all spark plugs.
Install ignition coils.
Replace crankshaft radial seal at front.
Remove special tool 11 9 190 / 11 5 120 .
Mount special tool 11 9 280 on hub for vibration damper.
Tighten down central bolt (1).
Tightening torque 11 23 6AZ
.
RA Replacing timing chain (N40)
