1 Series 125i (N52K) Convertible
51 61 ...
Removing and installing/replacing front
rollover protection system strut
Important!
Risk of damage!
Driving without the strut is not permitted!
Necessary preliminary tasks:
•
Remove rear seat back
Release screws (1).
Tightening torque 51 71 27AZ
.
Release screws (2) and remove strut (3).
Tightening torque 51 71 28AZ
.
Installation:
Replace all screws.
RA Removing and installing/replacing front rollover protection system strut
BMW AG - TIS
17.01.2013 16:40
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
