3 Series E36 316i (M43) TOUR
Installation:
Edge protection (2) must be fitted to bracket for left safety belt
(top belt) to protect wiring harness from damage.
Tightening torque for retaining screw (1),
refer to Technical Data 72 11 1AZ
Unfasten screw in left/right inertia reel unit.
Installation:
Locking device journal (1) for left/right inertia reel units must
locate in the grooves.
Tightening torque for retaining screw,
refer to Technical Data 72 11 1AZ
RA Removing and installing or replacing all rear seat safety belts (compl.) (tourin
