3 Series E36 318i (M40) SAL
12 14 520
Replacing pulse sensor on vibration damper
(M40)
Switch off ignition.
Removing fan coupling with fan and fan shroud.
Unfasten plug connection:
1.
Impulse sensor for cylinder recognition
2.
Impulse sensor on the vibration damper
Unclip electric cable guide in holder.
Release screw on pulse generator.
RA Replacing pulse sensor on vibration damper (M40)
BMW AG - TIS
21.01.2013 21:31
Issue status (12/2007) Valid only until next DVD is issued
