3 Series E36 328i (M52) COUPE
C nominal
9.12 mm
Y measured on dial gauge
1.92 mm
+ master disc thickness
7.00 mm
C actual
8.92 mm
C nominal
9.12 mm
C actual
- 8.92 mm
a
0.20 mm
master disc A
4.10 mm
- a
0.20 mm
Thickness of shim (X)
3.90 mm
If C nominal is greater than C actual, "a" is subtracted from
thickness of shim (X).
Example II:
RA Replacing drive pinion with crown wheel (Type K) - final drive removed -
