3 Series E46 M3 CSL (S54) COUPE

Page 1
background image

51 41 000

Removing and installing front left or right
door trim panel (M3 CSL)

Special tools required:

•

00 9 317

Press on point (A) and tilt out trim (1).

Release screw underneath.

Release screws (1).

Tightening torque,  51 41 2AZ

.

Unclip door trim panel (2) with special tool

00 9 317 .

Installation:

If necessary, replace faulty clips (1).

RA  Removing and installing front left or right door trim panel (M3 CSL)

BMW AG - TIS

16.02.2013  23:40

Issue status (12/2007) Valid only until next DVD is issued
