3 Series E46 M3 CSL (S54) COUPE
Carefully unclip door trim panel (1) at top with special tool
00 9 317 .
Feed out door trim (1) from unlocking knob (2).
Unhook Bowden cable for release lever:
-
Tighten release lever (1).
-
Lever out lock (2).
-
Detach Bowden cable (3) towards rear/top.
Installation:
For fitting, press release lever (1) fully onto door trim panel.
Disconnect plug connections (1).
Installation:
After assembling the door trim panel proceed as follows:
-
Open door window.
-
Lock with vehicle key.
-
Check for ease-of-movement on retaining button linkage
-
If necessary, align linkages
