3 Series E46 M3 (S54) COUPE
Installation:
Clean sealing surfaces (1). Note correct position of adapter
sleeves (2).
Note:
For a better overview, only a removed throttle assembly is shown.
Installation:
Clean sealing surfaces on cylinder head.
Replace all O-rings (1) in cylinder head.
Important!
After working on throttle system (throttle assembly,
servomotor, potentiometer), carry out electronic throttle test
with DIS Tester or MoDiC without fail:
-
Service functions
-
DME system checks
-
Function test
Installation:
Read out fault memory of control unit of Digital Motor Electronics
(DME).
Check stored fault messages.
Rectify faults.
Now clear the fault memory.
RA Removing and installing/sealing throttle assembly (S54)
