3 Series E46 M3 (S54) COUPE
61 71 100
Removing and installing/replacing windshield
washer pump (M3)
Note:
Drain fluid tank for windshield washer system
Remove cover on right.
Detach hose (1) in direction of arrow from windshield washer
pump (3).
Disconnect plug connection (2).
Turn windshield washer pump (3) in direction of arrow, lift out of
water reservoir for windshield washer system (4).
Installation:
Replace sealing ring/strainer of washer pump.
Coat sealing ring of washer pump with antiseize agent.
Ensure hose is laid without kinks.
Fill fluid tank for windshield washer system.
RA Removing and installing/replacing windshield washer pump (M3)
BMW AG - TIS
16.02.2013 23:44
Issue status (12/2007) Valid only until next DVD is issued
