3 Series E93 325d (M57T2) CONVER
Tie a safety knot into tensioning strap on left and right to prevent
the tensioning strap from coiling up.
Important!
Release safety knot after installation.
Release left and right screws (1).
Tightening torque: 54 37 14AZ
.
Release Torx screws (1) of reversing lugs for tensioning cable on
left and right.
Tightening torque: 54 37 15AZ
.
Release retainers (2) with screwdriver and pull roof liner (1) off
roof shell.
Installation:
Retainers (2) must not be damaged and must be pre-installed.
RA Removing and installing or replacing roofliner for roof shell in middle
