6 Series M6 (S85) Coupe
23 12 512
Replacing radial shaft seal for drive shaft
(GS7S47BG SMG)
Special tools required:
•
23 0 490
•
23 2 490
•
23 4 100
Important!
After completion of work, check gear oil level.
Use only approved transmission oil.
Failure to comply with this requirement will result in serious
damage to the manual transmission.
Necessary preliminary tasks:
•
Remove transmission
•
Remove clutch controller and release lever from guide tube.
Unfasten screws.
Tightening torque, 23 11 2AZ
.
Remove guide tube (1).
Installation:
Clean guide tube.
Do not grease guide tube.
RA Replacing radial shaft seal for drive shaft (GS7S47BG SMG)
