6 Series M6 (S85) Coupe
Note:
If necessary, gently heat air hose when firmly seated.
Disconnect hoses (2) and (3) from valve housing (1).
2
Hose (blue) top cushion
3
Hose (red) bottom cushion
Installation:
Air hoses (2) and (3) must be laid without kinks.
Detach lumbar cushion (1) from spring wire (2).
Version with seat heating:
Slide cable (3) for seat heating to one side.
Press back support (1) a little.
Turn lumbar cushion (2) and pull out downwards.
Installation:
Check lumbar cushion at top (1) and bottom (2) for damage.
Air hoses (3) must not be kinked.
RA Replacing lumbar cushion on front left or right seat
