6 Series E64 M6 (S85) CONVER
11 36 142
Removing and installing / replacing left inlet
VANOS gear (S85)
Special tools required:
•
11 3 302
•
11 5 100
•
11 5 291
•
11 5 292
•
11 5 302
•
11 5 320
•
11 5 352
•
11 5 370
•
11 5 381
•
11 5 382
•
11 5 410
Necessary preliminary tasks:
•
Remove left VANOS adjustment unit.
Important!
Both inlet and exhaust camshafts can be adjusted in the
1st cylinder firing TDC position.
The procedure for checking timing is different from that for
adjusting.
Secure special tool 11 5 320 to vibration damper in 1st cylinder
firing TDC position.
RA Removing and installing / replacing left inlet VANOS gear (S85)
