7 Series E38 730i (M60-1) SAL
11 12 Cylinder Head with Cover M60/1 B 30
Cylinder head height Original height
mm
140.0
Machining limit
mm
139.7
Valve guides are not available as replacement parts.
Valve guide interior
∅
(installed)
Standard
mm
6.0 H7
Size 1
mm
6.1 H7
Size 2
mm
6.2 H7
Max. tilt clearance
(wear between valve and valve guide)
mm
0.5
Camshaft bearing
Guide bearing width (cylinder head)
mm
28.85
-0.08
TD Cylinder Head with Cover, M60/1, B 30
