7 Series E38 730i (M60-1) SAL
11 12 Cylinder Head with Valve Seat Cover M60/1 B 30
Valve seat angle
°
45
Correction angle (outer)
°
15
Correction angle (inner)
°
60
Valve seat width (dimension "B")
Inlet
mm
1.25
±
0.25
Exhaust
mm
1.65
±
0.35
∅
Valve seat
Inlet outside dia.
mm
31.5
Exhaust outside dia.
mm
28.0
TD Cylinder Head with Valve Seat Cover, M60/1, B 30
