7 Series E38 730i (M60-1) SAL
11 21 Crankshaft and Bearings M60/1 B 30
Ground sizes of main bearing journals
Standard yellow
mm
69.984
+0.006
Standard green
mm
69.977
+0.006
Standard white
mm
69.971
+0.005
Stage 1 (U 0.25) yellow
mm
69.734
+0.006
Stage 1 (U 0.25) green
mm
69.727
+0.006
Stage 1 (U 0.25) white
mm
69.721
+0.005
Stage 2 (U 0.50) yellow
mm
69.484
+0.006
Stage 2 (U 0.50) green
mm
69.477
+0.006
Stage 2 (U 0.50) white
mm
69.471
+0.005
Undersize 3 (U 0.75 mm) yellow
mm
69.234
+0.006
Undersize 3 (U 0.75) green
mm
69.227
+0.006
Undersize 3 (U 0.75) white
mm
69.221
+0.005
Radial crankshaft bearing play
mm
0.020 ... 0.050
TD Crankshaft and Bearings, M60/1, B 30
