7 Series E38 730i (M60-1) SAL
11 24 Connecting Rods and Bearings M60/1 B 30
Dia. large conrod eye (without bearing shells)
mm
52.000 ... 52.013
Conrod bush inside diameter
mm
22
+0.012
+0.005
Permissible total deviation of
connecting rods (without bearing shells)
g
±
3
TD Connecting Rods and Bearings, M60/1, B 30
