7 Series E38 730i (M60-1) SAL
11 25 Pistons with Rings and Pins M60/1 B 30
Piston and pin are paired to each other - replace together
only.
Measuring point "A" (position)
mm
14
Piston dia. measuring point "A"
mm
83.976 ... 83.994
Piston running clearance
mm
0.006 ... 0.038
Permissible total wear tolerance between piston and
cylinder
(engine operated)
mm
0.1
TD Pistons with Rings and Pins, M60/1, B 30
