7 Series E38 730i (M60-1) SAL
26 11 Propeller shaft complete E38 / M60/1 / MECH / 730i Manual Transmission
Deflection torque of universal joints
Ncm
20 ... 70
Preload of center mount in forward direction
mm
2 ... 4
Deflection angle transmission/propeller shaft
-0
°
26' ... +0
°
34'
Deflection angle of center mount
-1
°
13' ... -0
°
13'
Deflection angle propeller shaft/final drive
+1
°
09' ... +2
°
09'
Explanation of deflection angle:
Propeller shaft bent upwards=
Deflection angle positive (+)
Propeller shaft bent downwards=
Deflection angle negative (-)
TD Propeller shaft complete, E38, M60/1, 730i, Manual Transmission
