7 Series E38 730i (M60-1) SAL
31 00 Front axle - ride height E38
Ride level in normal position (attach tape measure to rim
flange at bottom middle and measure to lower edge of
wheel arch)
Deviation from nominal value for all wheels together
Max. mm
10
Series
16" rim
mm
±
10
613
17" rim
mm
±
10
628
18" rim
mm
±
10
641
Low-slung sports suspension
16" rim
mm
593
17" rim
mm
608
18" rim
mm
621
Rough road package
16" rim
mm
±
10
635
17" rim
mm
±
10
650
18" rim
mm
±
10
663
TD Front axle - ride height E38
BMW AG - TIS
04.02.2013 22:24
Issue status (12/2007) Valid only until next DVD is issued
