7 Series E65 735i (N62) SAL
11 34 715
Replacing all valve springs (N62)
Special tools required:
•
11 0 346
•
11 9 470
(cylinder head removed)
Preliminary tasks are described in Disassembling and
assembling cylinder head.
Remove bearing bracket (1) with inlet camshaft and stow in
special tool 11 9 470 . The procedure is described in the
section Removing and installing inlet camshaft.
Remove exhaust camshaft.
RA Replacing all valve springs (N62)
BMW AG - TIS
08.02.2013 03:14
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
