X Series E53 X5 4.4i (M62) OFFRD
11 13 010
Removing and installing/replacing upper
section of oil sump (M62)
Note:
For removal of oil sump, front axle support must be
lowered.
There is no need to perform a front axle alignment check.
Instructions for disconnecting and connecting battery,
refer to General Information MG12.
Disconnect negative battery lead.
Remove heater bulkhead,
refer to 51 71 080.
Lift engine hood into assembly position.
Note:
The following work must be carried out with a second person
assisting. Work instruction applies to left and right sides.
Gently raise retaining clip and simultaneously push upwards.
Hold engine hood, unhook damper on hood. Open engine
hood fully and reattach damper with special tool 51 2 170
to hood.
Turn fasteners on acoustic cover 90
°
counterclockwise, remove
acoustic cover.
