X Series E70 X5 4.8i (N62TU) OFFRD
Release screws and remove holder (1).
Tightening torque 18 20 1AZ
.
Lower and remove front muffler with assistance of a second
person.
Installation:
Connect front muffler to rear muffler by means of clamps and
align.
Centre clamps and tighten down.
Tightening torque 18 20 5AZ
.
Installation:
Adjust front muffler to fit so that both tail pipes (1) of rear muffler
are centrally situated in openings in rear apron.
Installation:
Check rubber mount for damage, replace if necessary.
Check exhaust system for leaks.
RA Replacing front muffler (N62TU)
