X Series E70 X5 4.8i (N62TU) OFFRD
Important!
To protect the pistons, place a protective plate (2) (e.g. hard
wood or hard felt) in caliper recess.
Do not grip piston with fingers - risk of trapping!
Check guide sleeves (1), fitting repair-kit guide sleeve if
necessary.
Carefully force piston out through connection bore with
compressed air.
Installation:
Do not jam piston when pressing in.
Important!
Machining of cylinders and pistons is not permitted.
Carefully remove seal (1) with special tool 00 9 316 .
Clean cylinder bores and parts with alcohol and dry with
compressed air.
Thoroughly inspect cylinder bore, piston and flange surfaces.
Install new seal.
Installation:
Apply a light coat of Ate brake cylinder paste to cylinder bore,
piston and seal,
Refer to BMW Service Operating Fluids.
RA Overhauling left or right front brake caliper (brake caliper removed)
