X Series E70 X5 4.8i (N62TU) OFFRD
62 11 280
Removing and installing (replacing)
instrument cluster
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Note:
•
Comply with notes and instructions on handling fibre-optic
cables
Necessary preliminary tasks:
•
Extend steering wheel completely and lower
•
Disconnect battery negative lead
Release screws (1).
Pull back instrument cluster (2) slightly.
Disconnect associated plug connection.
Remove instrument cluster (2).
RA Removing and installing (replacing) instrument cluster
BMW AG - TIS
08.02.2013 14:07
Issue status (12/2007) Valid only until next DVD is issued
