Spindle: Service and Repair

Spindle Rod Replacement

Removal Procedure

1. Raise and support the vehicle. Refer to Vehicle Lifting.
2. Remove the tire and wheel assembly.

Important: Use a transmission jack or suitable hoist stands to prop the rear suspension support.

3. Lower the rear suspension support to gain clearance to the spindle rod to suspension support bolt. Refer to Support Replacement.
4. Remove the bolt (1 or 2) and nut from the spindle rod and the rear suspension support.

5. Remove the spindle rod to knuckle bolt and nut.
6. Remove the spindle rod (1) from the vehicle.

Installation Procedure
