LaCrosse V6-3.8L (2009)
Splash Guard: Service and Repair
Engine Splash Shield Replacement
Special Tools
J 38778 Door Trim Pad Clip Remover
Removal Procedure
1. Use the J 38778 in order to remove the push-in retainers from the engine splash shield.
2. Remove the engine splash shield from the lower flange of the engine compartment side rail.
Installation Procedure
